Capital 300 Ultra Spot Static White

CP300US
CP300USPE Polar Edition
  • Powerful floodlight fitted with efficient ultra-spot optics for long-shot effects at remarkable distances with accurate beam angle definition
  • Max. delivered lm output: 9929 lm / 64 lm/W
  • Control system: DMX-RDM
  • 19.4" L x 4.1" W x 15.1" H
View finishes: Anthracite Grey
  • Anthracite Grey
  • Black
  • Griven Silver Grey
  • White
  • Contact factory for Custom RAL or Marine Grade Finishes
View LED colour configuration: Warm White 3000K
  • Warm White 2700K
  • Warm White 3000K
  • Neutral White 4000K
Contact us  Save product
STATIC WHITE
print

Capital 300 Ultra Spot Static White

General Features

CAPITAL 300 US accentuates the designer’s palette with an ultra-narrow 3.2° beam using 60 high-power LEDs fitted with precision optics. Grazing of vertical columnar features or illumination of objects at distance both benefit from the high-performance of this luminaire.
Color configuration
High brightness 4000K Natural White, 3000k or 2700K Warm White or, on request, monochrome power LEDs
Optical configuration
3.2° US (Ultra Spot)
Max. Delivered lumen output
Up to 9929 lumens
Max. lumen/Watt
Up to 64 lumens per watt
Input voltage
120 - 277V
Amperage
1.3A @ 120VAC, 0.56A @ 277V
Power consumption
156 watts max.
Ingress protection rating
IP67
Impact resistance rating
IK09
External operating limits
-40°C to 50°C / (-40°F to 122°F)
Warranty
Five Year Limited Warranty
Accessories
Optional optical distribution and mounting accessories available for the utmost design flexibility.

Light Beam Effects

  • Ultra Spot


Overview

  • IP67
  • IK09
  • DMX
  • RDM
  • Rohs
  • ETL Listed

Optional Features

  • Optional Polar

Downloads

Specification SheetSpecification Sheet
PDF
Overview PresentationOverview Presentation
PDF
ConfigurationConfiguration
PDF
User ManualUser Manual
PDF
PicturesPictures
ZIP
IESIES
ZIP
REVITREVIT
ZIP
