Color configuration
High brightness Cool White, Natural White, Warm White
Optical configuration
7° US (Ultra Spot)
12° SP (Spot)
15° NB (Narrow)
23° MB (Medium)
44° WB (Wide)
60° EW (Extra wide)
130° UW (Ultra Wide)
40°h x 14°v ELH (Elliptical Horizontal)
14°h x 40°v ELV (Elliptical Vertical)
37°h x 23°v ELWH (Elliptical Wide Horizontal)
23°h x 37°v ELWV (Elliptical Wide Vertical)
Max. Delivered lumen output
98.7 (lm/W) CW
Max. nominal lumen output
20036 lumens @ 12° CW
Power consumption
203W 1.73A @ 115VAC, 0.77A @ 277VAC
Ingress protection rating
IP66
External operating limits
-40°C to 50°C / (-40°F to 122°F)
Accessories
Optional optical distribution and mounting accessories available for the utmost design flexibility and to be ordered separately.
