Capital 300 Ultra Spot RGBW

All products spot/flood/wash capital 300Capital 300 Ultra Spot RGBW

Capital 300 Ultra Spot RGBW

CP300US
CP300USPE Polar Edition

Powerful ﬂoodlight ﬁtted with eﬃcient ultra-spot optics for long-shot eﬀects at remarkable distances with accurate beam angle deﬁnition
Max. delivered lm output: 6729 lm / 43 lm/W
Control system: DMX-RDM
19.4" L x 4.1" W x 15.1" H

View finishes: Anthracite Grey

View LED colour configuration: RGBW (4000K White)

Contact us Save product

COLOR CHANGING

Capital 300 Ultra Spot RGBW18207

print

Capital 300 Ultra Spot RGBW

General Features

CAPITAL 300 US accentuates the designer’s palette with an ultra-narrow 3.2° beam using 60 high-power LEDs fitted with precision optics. Grazing of vertical columnar features or illumination of objects at distance both benefit from the high-performance of this luminaire.

Color configuration

High brightness RGB+W 4000K or 3000K LEDs

Optical configuration

3.2° US (Ultra Spot)

Max. Delivered lumen output

Up to 6729 lumens

Max. lumen/Watt

Up to 43 lumens per watt

Input voltage

120 - 277V

Amperage

1.3A @ 120VAC, 0.56A @ 277V

Power consumption

156 watts max.

Ingress protection rating

IP67

Impact resistance rating

IK09

External operating limits

-40°C to 50°C / (-40°F to 122°F)

Warranty

5-year warranty

Accessories

Optional optical distribution and mounting accessories available for the utmost design flexibility.

Light Beam Effects

Overview

Optional Features

Downloads

Specification Sheet

Specification Sheet

Configuration

User Manual

Pictures

IES

REVIT

Configuration

Capital 300 Ultra Spot RGBW

Model

CP300US Capital 300 US
CP300USPE Capital 300 US Polar Edition

Color

RGBW (3000K White)
RGBW (4000K White)

Control

DMX/RDM

Cable

Power in, DMX in, DMX out
Monocable with connectors
Monocable without connectors

Voltage

120-277V

Optic

Ultra Spot 3.2°

Finish

Anthracite Grey
Black
Griven Silver Grey
White

Option

Anti-Saline Treatment
3G Mounting Yoke

Optional Accessories

Infrared Configuration Remote

Infrared Configuration Remote

IR-CONFIG-REMOTE

Control & Installation Solutions

Snoot

Snoot

CP300-SNOOT-XX

Control & Installation Solutions

Visor

Visor

CP300-VISOR-XX

Control & Installation Solutions

Wire guard

Wire guard

CP300-WIREGUARD-XX

Control & Installation Solutions
